Ubiquiti UniFi Network Switch Dream Machine Pro Max (UDM-Pro-Max)-10G CloudGat-200+UniFi/2K+client
UDM-002
----------------------------
* 8 × Gigabit RJ45
- 1 × 10G SFP+ LAN Port
- 1 × 2.5GbE RJ45
- 1 × 10G SFP+ WAN
- 5 Gbps IDS/IPS Security Throughput
- 2.5G WAN + 10G SFP+ WAN
- 10G SFP+ LAN Uplink
- 8GB RAM & 128GB SSD
- Dual HDD Bays for UniFi Protect
- Supports Large UniFi Deployments
- Rackmount 1U Enterprise Gateway
- All-in-One Router, Firewall, Controller & NVR
- Bluetooth for easy setup
- 1Year warranty
-Dimensions: 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
*UniFi Application Suite
-Network: ✓
-Protect: ✓
-Access: ✓
-Talk: ✓
-Connect: ✓
*Managed UniFi Devices: 200+
-Managed Cameras: (50) HD / (25) 2K/ (15) 4K
-Managed Access Hubs: 150
-Simultaneous Users Connected: 2,000+
-Max. WAN Port Count: 8
-Default WAN Ports: (1) 10G SFP+ / (1) 2.5 GbE RJ45
*Port Layout
-1 GbE RJ45: 8 (1G/100M/10M)
-2.5 GbE RJ45: 1 (2.5G/1G/100M/10M)
-10G SFP+: 2 (10G/1G)
-IDS/IPS Throughput: 5 Gbps
-Form Factor: Rack mount (1U)
-Redundancy: Shadow Mode (VRRP) Gateway Failover DC Power Backup
*IDS/IPS Signatures: 55,000+ with CyberSecure
*NVR Storage:
-(2) 3.5" NVR HDD bays
-Built-in 128 GB SSD for Faster Experience
-Max. Power Consumption: 60W
*Processor: Quad-core ARM® Cortex®-A57 at 2.0 GHz
*System Memory: 8 GB
*On-board Storage: 32 GB eMMC / 128 GB SSD (Integrated)
*LCM Display: 1.3" touchscreen
*Management: Ethernet / Bluetooth
*Power Method
-(1) Universal AC input, 100–240V AC, 2A Max., 50/60 Hz
-(1) USP-RPS DC input, 11.5V DC, 8.7A
-Power Supply: AC/DC, internal, 100W
-Weight: 4.7 kg (10.4 lb)
